DBA Scripts: Get Disk Space on SQL Server

---

A SQL Server that runs out of disk stops taking writes, and depending on which volume filled up, that can mean suspended databases, a frozen transaction log, or failed backups at exactly the wrong moment. Disk space is the least glamorous thing a DBA monitors and the single most common cause of a 2am callout.

The catch for DBAs is access. On many production servers you have SQL access but not an RDP session, so checking drive space “the normal way” is not an option. Fortunately SQL Server can report on the volumes it uses by itself.

This script queries sys.dm_os_volume_stats through T-SQL alone and returns one row per volume hosting database files: total, free, used, and free percentage, most-full volume first.

---

Why Disk Space Matters

SQL Server does not degrade gracefully when a volume fills. A full data volume means autogrow fails and inserts start throwing errors. A full log volume freezes every write in the database with error 9002, and if that database is tempdb, the whole instance is effectively down. A full backup target quietly breaks your recovery point until someone notices the failed jobs.

The free_pct column is your early-warning line, but the free GB matters just as much: 10% free on a 4TB volume is plenty of runway, while 10% on a 100GB volume can vanish inside one index rebuild. Judge both together, in the context of how fast your databases grow.

• Full data volume: autogrow fails, writes error out
• Full log volume: transactions freeze with error 9002
• Full backup volume: recovery point drifts silently

---

When to Run This Script

• Routine SQL Server health checks
• When autogrow failures or error 9002 (transaction log full) appear
• Before large operations: index rebuilds, bulk loads, big restores
• During capacity planning, alongside database growth trends
• On servers where you have SQL access but no OS/RDP access

---

The Script

Run the following script against your SQL Server instance.

/*
Script Name : Get-DiskSpace
Category    : storage-capacity-management
Purpose     : Show free and used space per volume that hosts SQL Server database files.
Author      : Peter Whyte (https://sqldba.blog/dba-scripts-get-disk-space/)
Requires    : VIEW SERVER STATE
Notes       : Uses sys.dm_os_volume_stats — shows only volumes with at least one database
              file. For OS-level disk summary across all drives use Get-DiskSpaceSummary.ps1.
HealthCheck : Yes
*/
-- SAFE:ReadOnly
-- IMPACT:Low
SET NOCOUNT ON;

-- Group on the volume identity only: total/available bytes can change between file
-- samples mid-query, which duplicated volume rows when they were in the GROUP BY.
SELECT
    vs.volume_mount_point,
    vs.logical_volume_name,
    CAST(MAX(vs.total_bytes)     / 1024.0 / 1024 / 1024 AS DECIMAL(10,2)) AS total_gb,
    CAST(MIN(vs.available_bytes) / 1024.0 / 1024 / 1024 AS DECIMAL(10,2)) AS free_gb,
    CAST((MAX(vs.total_bytes) - MIN(vs.available_bytes)) / 1024.0 / 1024 / 1024
         AS DECIMAL(10,2))                                                AS used_gb,
    CAST(100.0 * MIN(vs.available_bytes) / NULLIF(MAX(vs.total_bytes), 0)
         AS DECIMAL(5,1))                                                 AS free_pct
FROM sys.master_files AS mf
CROSS APPLY sys.dm_os_volume_stats(mf.database_id, mf.file_id) AS vs
GROUP BY vs.volume_mount_point, vs.logical_volume_name
ORDER BY free_pct ASC;

It resolves every database file to its hosting volume and returns one deduplicated row per volume, ordered so the fullest disk is at the top.

---

How To Run From The Repo

Clone DBA Tools, initialize and run the script:

# Clone dba-tools repo:
git clone https://github.com/peterwhyte-lgtm/dba-tools

# Initialize environment:
cd dba-tools

.\Initialize-Environment.ps1

# Check free disk space on SQL Server volumes:
.\run.ps1 Get-DiskSpace

# To run against a remote sql server:
.\run.ps1 Get-DiskSpace -ServerInstance SQLSERVER01

This script lives in the repo at:

• sql/monitoring/disk-space/Get-DiskSpace.sql
• powershell/wrappers/monitoring/disk-space/Get-DiskSpace.ps1

---

Example Output

This example is a live capture and the top row is a genuine red alert: the C:\ volume hosting system databases has 1.2% free. That is the kind of finding this script exists to surface before SQL Server does it the hard way.

---

Understanding the Results

Under 10% free, or under one growth-cycle of headroom: act now. Between autogrow events, log growth during index maintenance, and tempdb expansion, a volume in this band can fill mid-operation.

10 to 20% free: plan the expansion or cleanup this week rather than this quarter, especially on smaller volumes where the percentage overstates the runway.

Remember what this view cannot see. It only reports volumes hosting database files. Backup targets on separate volumes or UNC shares, and the OS drive if no database files live there, need OS-level monitoring (the repo’s Get-DiskSpaceSummary.ps1 covers local drives from PowerShell).

---

How to Free Disk Space on a SQL Server Volume

Find what grew. Database file sizes and free space inside each file tell you whether the space went to data, logs, or tempdb, and the repo’s database sizes script breaks that down per database.

Transaction logs are the usual suspect. A log that ballooned once (a huge delete, a stalled log backup chain, a long-running transaction) keeps that size forever until you shrink it deliberately. Fix the cause first, confirm log backups are running, then a one-off DBCC SHRINKFILE on the log is legitimate.

Do not shrink data files as routine maintenance. It fragments indexes and the space usually grows right back. Reserve it for genuine one-off reclaims after archiving or purging.

Check for non-database tenants. Old backup files, memory dumps, and forgotten copies of detached databases love living on SQL volumes.

---

Related Scripts

You may also find these scripts useful:

• Storage and Capacity (hub)
• Autogrowth History
• Database Free Space Summary
• Database Sizes and Free Space
• Database Files Detail
• Filegroup Space
• Database Growth Risk and Forecast
• VLF Counts
• DBA Scripts: The Complete Guide, the map across every script on this site

---

Common Questions

Summary

Every SQL Server outage caused by a full disk was visible days earlier to anyone who looked. This script makes looking cheap: one query, one row per volume, fullest first, from inside SQL Server where DBAs actually have access.

It runs as part of the repo’s health-check collection for exactly that reason. Watch the top row, judge percentage and absolute GB together, and treat a shrinking number on a log volume as an incident in progress rather than a trend to watch.
